EQUUS 39

EQUUS is a LED spotlight suitable for indoor and outdoor installations. The innovative award winning design allows the luminaire to be pivoted and rotated in any direction so that the light can be aimed more effectively to illuminate a garden landscape or highlight a feature.

Product Description

The housing body is made from single cast bronze or stainless steel providing optimum thermal management.

Line voltage 100 ~ 270 50/60Hz
Integrated IP67 LED driver. Mains cable
termination is done via an IP68 external
cable gland with integral terminal.
High Power LED on MCPCB with Optical
Grade PMMA lens with high UV and
temperature resistance.
Protection class : IP66 Dust proof and
strong water jet proof.
Weight : 1.75kg (Stainless Steel)
2.0kg (Bronze)

Standard Configuration
Colour Temperature (k)2700K3000K4000K
Light DistributionSpotMedium
HousingStainless Steel (SS316)
Wattage5W
Optional AccessoriesSnootVisorLinear Spread lensColour Filter (Blue, Green, Red)Honeycomb Louvre
Mounting AccessoryPedestal BracketGround StakeTree StrapTree Strap
Part No.PowerColour TemperatureNominal LumensBeam AnglePDFIES
SPL02.2701.6.SS.xx5W2700K442 lm
SPL02.3001.6.SS.xx5W3000K503 lm
SPL02.4001.6.SS.xx5W4000K557 lm
SPL02.2701.26.SS.xx5W2700K442 lm26°
SPL02.3001.26.SS.xx5W3000K503 lm26°
SPL02.4001.26.SS.xx5W4000K557 lm26°
Standard Configuration
Colour Temperature (k)2700K3000K4000K
Light DistributionSpotMediumWide
HousingBronze
Wattage6W
Optional AccessoriesSnootVisorLinear Spread lensColour Filter (Blue, Green, Red)Honeycomb Louvre
Mounting AccessoryPedestal BracketGround StakeTree StrapTree Strap
Part No.PowerColour TemperatureNominal LumensBeam AnglePDFIES Files
SPL02.2701.6.B.xx6W2700K556 lm
SPL02.3001.6.B.xx6W3000K624 lm
SPL02.4001.6.B.xx6W4000K656 lm
SPL02.2701.26.B.xx6W2700K556 lm26°
SPL02.3001.26.B.xx6W3000K624 lm26°
SPL02.4001.26.B.xx6W4000K656 lm26°
